Application Scope
Juice concentration: For example, orange juice, apple juice, etc. They can evaporate at low temperatures, effectively preserving the nutrients and flavors in the juice.
Milk and dairy product concentration: Such as milk, yogurt, etc. This can increase the product's concentration and extend its shelf - life.
Syrup and sweetener concentration: For instance, syrups, oligofructose, etc. They can efficiently remove moisture and enhance the product's concentration.
Concentration of other food products: Such as seasonings, soups, etc. They are applicable to the concentration treatment of various liquid food products.
Model Specifications
Model | Evaporation capacity（L） | Steam consumption（kg/H） | Power （kw) | Overall dimensions （L×W×H） |
CXP-NS-JM2000 | 2000 | 800
| 60
| 8000×3900×9600(mm) |
CXP-NS-JM3000 | 3000 | 900 | 90 | 8000×4800×9600(mm) |
CXP-NS-JM4500 | 4500 | 1300 | 120 | 12000×8000×10000(mm) |
Equipment Features
High heat transfer efficiency: It adopts the principle of thin - film evaporation, with low thermal resistance. The heat transfer coefficient is usually in the range of 500 - 3000W/(m²·°C), which can quickly transfer heat energy to liquid materials and improve the evaporation efficiency.
Short material heating time: Since the liquid forms a thin film inside the heating tubes, the heating time is short, avoiding the deterioration of materials due to long - term heating. It is especially suitable for the treatment of heat - sensitive materials.
Energy - saving: Multi - effect falling - film evaporators (such as triple - effect and quadruple - effect ones) make use of steam heat in a cascading manner, significantly reducing energy consumption. With a high steam utilization rate, the energy consumption is only about one - third of that of a general evaporator.
High degree of automation: The equipment is easy to operate and easy to achieve automated control, reducing manual intervention and operating costs, and improving production efficiency.
Strong adaptability: It can adapt to solutions of different concentrations and properties, and is widely used in various industries and for the treatment of different types of materials.
Environmental protection and safety: The equipment has good sealing performance, complies with environmental protection requirements, ensures safety and reliability during the production process, and does not generate a large amount of wastewater and waste gas, thus protecting the environment.
Convenient cleaning: Equipped with a CIP (Clean - In - Place) system, the equipment can be thoroughly cleaned without disassembly. It is convenient for operation and maintenance, ensuring the cleanliness and normal operation of the equipment.
